JIANGSU WANSHIDA 유압 기계 CO., LTD
| 원래 장소: | 중국 |
|---|---|
| 브랜드 이름: | WANSHIDA |
| 인증: | CE and ISO9001 |
| 모델 번호: | Y82-25 |
| 최소 주문 수량: | 1세트 |
| 가격: | 협상 가능 |
| 포장 세부 사항: | 항해에 적합한 포장 |
| 배달 시간: | 30일 |
| 지불 조건: | 티/티 |
| 공급 능력: | 10 세트/월 |
| 이름: | 덤블 크레셔 | 모델: | Y82-25 |
|---|---|---|---|
| 맥스 포스 포스: | 250kn | 뇌졸중: | 1000mm |
| 압축 상자 크기(LxW xH): | 790x790x1060mm | Baled Block의 크기 (H): | 최소 60mm |
| 유압 시스템 압력: | 21 MPa | 전동기: | Y160M -4 |
| 힘: | 11kW | 전체 크기 (LXW XH): | 1150x1500x2950mm |
The Y82-25 Drum Crusher is a compact yet powerful hydraulic machine designed for compressing 200L steel drums. It is widely used in industrial waste recycling, especially in facilities dealing with oil drums, chemical containers, and metal barrels.
With a maximum press force of 250kN, this drum crusher can reduce drum height to as low as 60 mm, significantly decreasing storage space and transportation costs. In many recycling plants, operators often struggle with bulky drums occupying large areas—this machine provides a practical and efficient solution.
Its stable hydraulic system and robust structure ensure reliable operation even under continuous working conditions.
| Item | Parameter |
|---|---|
| Model | Y82-25 |
| Max Push Force | 250 kN |
| Stroke | 1000 mm |
| Chamber Size | 790×790×1060 mm |
| Final Height | Min. 60 mm |
| Hydraulic Pressure | 21 MPa |
| Motor | Y160M-4 |
| Power | 11 kW |
| Overall Size | 1150×1500×2950 mm |
| Weight | 1800 kg |
Q: What type of drums can this machine handle?
A: Mainly 200L steel drums, including oil and chemical barrels.
Q: Can it operate continuously?
A: Yes, the hydraulic system is designed for stable continuous operation.
Q: Is customization available?
A: Yes, we can adjust specifications based on your requirements.
